Infrastructure sector is highly responsible for propelling India's overall development and enjoys intense focus from government for initiating policies that would ensure time-bound creation of world class infrastructure in the country. Infrastructure development particularly in roads, bridges, dams, tunnels is the need of the hour for India. The efficient management of bridge construction is dependent on many factors like design and length of the bridge, material and manpower requirement, area where it is being built, technology being used etc. Due to these requirements, identification and selection of necessary construction equipment is important.

When we talk about Bridge & Road construction; Compactors, Graders and Dozers are the prime equipment used for different job-works. Under compaction segment, CASE offers 752EX (9T Class) Vibratory Tandem Compactor and 450DX Mini Tandem Compactor (3T Class). In soil compactors, CASE offers 1110 EX and 1107 EX for perfect for uniform compaction across terrain. This wide range of equipment illustrates the brand's ability to cater for activities as diverse as urban construction, road building, infrastructure, bridge construction.

The CASE 752EX is equipped with a fuel-efficient FPT engine that delivers 76 HP at 2200 rpm and torque of 332 Nm at 1300 rpm. This new-generation engine - developed by CNH Industrial subsidiary FPT Industrial, the world-leading manufacturer of engines, transmissions and powertrains - provides outstanding performance, fast response times, and best-in-class fuel economy. The 752EX's operator compartment features a rotating operator seat and tiltable steering which gives excellent front and rear drum/nozzle visibility, making the drive and compaction process easier and safer. The look of the machine is enhanced by foldable canopy for ease of transportation, new fuel and water tanks and new sophisticated instrument cluster.

CASE 1107EX soil compactor featuring a new FPT Industrial S8000 engine that delivers 100 HP at 2200 rpm. The turbo after cooled engine with internal Exhaust Gas Recirculation ensures best-in-class fuel economy. More than 2 million S8000 engines at work across the world are testament to the reliability of this proven power. The maximum applied force in the range of 34 tonnes is among the best in the industry. The hydrostatic variable speed control ensures the CASE 1107EX travels at the perfect speed for every type of soil, resulting in a uniform compaction.

CASE 450DX market leader in mini tandem compactor segment in India with more than 1600 machine population powered by Mahindra Industrial (MDI 2500) water-cooled diesel engine developing 45HP ensure best in class fuel efficiency and productivity. Mahindra MDI 2500 is proven and reliable engine in Indian condition and having huge population in India hence easy to get service and parts support. This machine with operating weight 3225 Kgs is a very popular choice for bituminous compaction and has tandem drums with dual frequency of 55 Hz and 65 Hz at amplitudes of 0.6mm developing maximum applied force of 6035 Kgf per drum. 450DX is perfectly suited for Shoulder compaction, Service roads and basement compaction with compact design (Length – 2.9 m, Width – 1.3 m).

CASE 1110EX-D with HVAC Cabin, soil compactor featuring a new FPT Industrial S8000 engine that delivers 110 HP at 2300 rpm and torque of 430 Nm at 1400 rpm. The turbo after cooled engine with internal Exhaust Gas Recirculation ensures best-in-class fuel economy. More than 2 million S8000 engines at work across the world are testament to the reliability of this proven power. The maximum applied force in the range of 34 tonnes is among the best in the industry.  Machine is fit for mining application and is available in two variants -Drum Drive and Pad Foot Drum, equipped with ROPS/FOPS HVAC cabin catering to operator's comfort and safety.

CASE Construction offers a range of Graders, mainly for Mining & Road Construction and irrigation projetcs. Two different models (CASE 845B and CASE 865B)  are available for the Indian market. These machines are manufactured in and imported from Brazil.

The main features of CASE 845B ideal for road construction & CASE 865B ideal for mining application are-

• Fuel Efficient FPT Engine VHP – Both the 845B and 865B are equipped with an FPT engine with Variable Horse Power(845B along with dual HP-150HP / 173HP and 865B with triple HP- 193HP /205 HP / 220 HP) :  it delivers maximum performance with minimum fuel consumption in any working condition. There are more than 2 lakh FPT engines working extraordinarily well in the field today, -  A testament to the reliability of the engine performance

• Multi Radius Moldboard

CASE Motor Graders are fitted with an exclusive Moldboard with a patented Multiradius profile, which not only pushes the material, but also induces material roll-off. This reduces the load on the blade, and hence results in better productivity & excellent Fuel efficiency. The Moldboard features best-in-class thickness of 22mm, which greatly enhances the durability. Hydraulic pitch adjustment allows operators to easily control moldboard from the cabin.

• Heavy Duty A-Frame

The “A” frame of the drawbar is robust and rigid. Larger wear surface provides longer life (reduces wear) and the Externally driven circle is easy to clean and better protected in case of shocks.

• Comfortable Operator Compartment

The closed cabin of the CASE Graders is Air conditioned & roomy, and provides the operator with a Comfortable & silent work environment to work in. The seat, levers & inclinable console are ergonomically laid out.  The rear mounted cab allows remains facing the direction of travel, even when articulating. As a result, visibility of the moldboard and the front is excellent.

• Easy Serviceability : It's easy to service & maintain CASE Graders. A single piece engine hood, with 90° turnable battery provides full access to engine compartment and all check points from ground level.

All these advantages allow the operator to focus on completing the job faster, while being enhancing Productivity and saving money.
